Audio Visual CAD Blocks
Audio visual CAD blocks free in DWG, DXF, PNG, and PDF. The 29 symbols cover sound and video gear along with the power sources and switches that feed it.
Key Features
ArcSite's Audio Visual CAD Blocks
- Sound and Video: A speaker, a microphone, and a camera mark where AV gear goes in a room.
- Backup Power: UPS, generator, battery, and transformer symbols show what keeps the system running in an outage.
- Renewable Sources: Solar panel and wind turbine symbols cover off-grid and hybrid setups.
- Wall Devices: A toggle switch and a duplex outlet sit on the elevation beside the gear they control.
- EV Charging: Two car symbols mark charger spots in a garage or parking area.
Unlock 1,200+ Free CAD blocks with the ArcSite app
CAD blocks. Floor plans. Estimates. Do it all with ArcSite's mobile app.
Free access to over +1,200 blocks included with the ArcSite CAD app
Trusted by the Pros. Honored for Innovation.
Based on 21,000+ reviews from
Security, AV & Technology
CAD blocks you might like
FAQs
How many symbols are in the set?
29, from speakers and microphones to generators and solar panels.
Can I use it to plan where AV gear gets power?
Yes, put an outlet or UPS symbol next to each speaker or camera so the electrician sees which ones need a circuit.
What formats is it available in?
DWG, DXF, PNG, and PDF.
