Architectural CAD Blocks
Architectural CAD blocks free in DWG, DXF, PNG, and PDF. The set covers straight, switchback, and spiral stairs, an elevator, a north arrow, and solid and hatched fills.
Key Features
ArcSite's Architectural CAD Blocks
- Stair Variations: Straight, switchback, and spiral stairs cover the most common runs on a floor plan.
- Elevator Symbol: A plan view elevator car and shaft for multi-story and commercial layouts.
- North Arrow: Orient every sheet with a filled north arrow labeled "N".
- Fill and Hatch Symbols: Solid and hatched shapes mark columns, openings, and areas to call out.
- One Download, Full Set: Get every symbol in a single file instead of hunting for each one.
Unlock 1,200+ Free CAD blocks with the ArcSite app
CAD blocks. Floor plans. Estimates. Do it all with ArcSite's mobile app.
Free access to over +1,200 blocks included with the ArcSite CAD app
Trusted by the Pros. Honored for Innovation.
Based on 21,000+ reviews from
Architectural Symbols & Site Annotation
CAD blocks you might like
FAQs
What symbols are in the set?
Stairs, a spiral stair, an elevator, a north arrow, solid columns, and hatched area fills.
