Carbon Fiber For Footing CAD Block
Carbon fiber footing reinforcement CAD block free in DWG, DXF, and PNG. Reinforce any footing crack or joint on Windows, iOS, or Android.
Key Features
ArcSite's Carbon Fiber For Footing CAD Block
Footing-Scaled Strip: Sized for footing width rather than wall height
Set at the Footing Line: Placed with reference points along the footing rather than the wall above it
Editable Label Field: Included for strip count or spacing notes
Horizontal Orientation: Set to match real footing runs instead of a vertical wall strip
