Fireplace Architecture CAD Block

Fireplace Architecture CAD Block

Fireplace architecture CAD block free in DWG, DXF, PNG, and PDF. Includes the mantel, surround, and firebox opening in one drop-in block.

Customize & Download

Opens right in your browser — no install. Make it yours within minutes.

Browse Related Blocks
Fireplace Architecture CAD Block

Key Features

  • Full Surround Included: Mantel, side legs, and hearth are drawn together as one block.
  • Firebox Opening Built In: The opening is sized to standard proportions so it reads correctly at any scale.
  • Works for Interior Elevations: Use it wherever a living room, den, or great room elevation needs a fireplace wall.
  • Easy Integration: Insert into ArcSite drawings instantly, or export DWG/DXF formats for use in any standard designing software.
  • Compatibility with CAD software: The fireplace architecture CAD block can be viewed in most CAD software, including AutoCAD and ArcSite.

‍

Accurate to scale

Professional results

Ready made to share or export
