Dumbbell Rack CAD Block
Dumbbell rack CAD block free in DWG, DXF, and PNG. Set the rack and the lifting space in front of it.
Key Features
ArcSite's Dumbbell Rack CAD Block
- Two-Tier Layout: Six dumbbells on the top tier and five on the bottom show a fully loaded rack.
- End Posts: Solid uprights on each side mark the rack's full width for wall placement.
- Lighter on Top: Smaller dumbbells sit on the top tier and larger ones below, the way most commercial racks are loaded.
- Lifting Zone Planning: Leave open floor in front of the rack so lifters can pull weights and step back.
